Roadmachine FOUR
The Roadmachine brings big tire capabilities to its proven endurance platform to make every ride better. Built with Shimano’s 105 Di2 groupset and fitted with road-smoothing 30mm tires on a set of Mavic Open Disc wheels, the Roadmachine FOUR also fea
The Roadmachine brings big tire capabilities to its proven endurance platform to make every ride better. Built with Shimano’s 105 Di2 groupset and fitted with road-smoothing 30mm tires on a set of Mavic Open Disc wheels, the Roadmachine FOUR also features many of our innovative technologies, such as a Premium Carbon D-Shape seatpost to ensure next-level compliance and integrated downtube storage for peace of mind.
- Shimano 105 Di2 Drivetrain
- Mavic Open Disc Wheelset
- Carbon D-Shape Seatpost
Specifications are subject to change without notice. All bike and frame weights are based off pre-production painted frames. Weights may vary in final production.
Returns & Price Matching
| Component | Part |
|---|---|
| Frame | Roadmachine Carbon with Tuned Compliance Concept Endurance, Fender Mounts, Integrated Downtube Storage, Stealth Dropout Design, 12 x 142mm Thru-Axle |
| Fork | Roadmachine Carbon with Tuned Compliance Concept Endurance, Fender Mounts, Stealth Dropout Design, Flat Mount Disc, 12 x 100mm Thru-Axle |
| Stem | BMC RSM 01 |
| Handlebar | BMC RAB 03, Ergo Top Shape, Compact Bend |
| Seatpost | Roadmachine Carbon D-Shaped Seatpost, 15mm Offset, D-Fender Compatible |
| Saddle | Fizik Taiga or Selle Royal SRX |
| Crankset | SHIMANO 105 (FC-R7100) |
| Chainrings | 50-34T |
| Cassette | SHIMANO 105 (CS-R7100) |
| Cassette Size | 11-34T |
| Chain | SHIMANO CN-M6100 |
| Front Derailleur | SHIMANO 105 Di2 (FD-R7150) |
| Rear Derailleur | SHIMANO 105 Di2 (RD-R7150) |
| Shifters | SHIMANO 105 Di2 (ST-R7170) |
| Gears | 2 x 12 |
| Bottom Bracket | PF86 Bottom Bracket |
| Brake Levers / Calipers | SHIMANO 105 (BR-R7170) |
| Rotors | SHIMANO SM-RT70 |
| Rotor Size (F/R) | 160 / 140mm |
| Rims | Mavic Open Disc |
| Hubs (F/R) | CL-712 (F), RXC-1425 (R), Thru-Axle |
| Tires | Vittoria Rubino IV G2.0, Tube only, 30mm |
| Tubeless Information | Tubetype Rims, Tubetype Tires |
| Tire Clearance | up to "40mm measured" (frameset clearance) but limited to "34mm measured" by the front derailleur |
| Weight without Pedals | 8.6 kg |
| ASTM Classification | Level 2 |
| System Weight Limit | 110kg |
* Specs subject to change
