Ripmo V3 Deore
The Ripmo isn't just a bike; it's a legend. With multiple "Best in Test" awards and years of high level competition at the notoriously brutal Enduro World Series, it’s the ultimate trail-slaying machine. How do you improve on that? The new Ripmo is l
The Ripmo isn't just a bike; it's a legend. With multiple "Best in Test" awards and years of high level competition at the notoriously brutal Enduro World Series, it’s the ultimate trail-slaying machine. How do you improve on that? The new Ripmo is loaded with new features: internal downtube storage, a flip chip for mixed wheels, a slacker head angle, and increased coil compatibility. Ibis also expanded their sizing options and added size-specific details—right down to the bottom bracket height.
Images may not show actual build kit content. Specifications are subject to change without notice. All bike and frame weights are based off pre-production painted frames. Weights may vary in final production.
Returns & Price Matching
| Component | Part |
|---|---|
| Frame Material | Carbon front and rear triangle |
| Fork | Marzocchi Bomber Z1, 160mm, 29", 110x15mm (Medium spring installed) |
| Shock | Fox Float X, Factory Series, 2-Pos Adj. w/EVOL, 230mm x 60mm |
| Wheels | Blackbird Send Alloy, 32 Hole, Ibis Logo Hubs S-M, F: Send I 29" R: Send II 27.5" XM-XL, F: Send I 29" R: Send II 29" |
| Front Tire | Maxxis DHF, 29" x 2.5", Exo+ |
| Rear Tire | Maxxis DHR II, Exo+ S-M: 27.5" x 2.5", XM-XL: 29" x 2.5" |
| Brakes | Shimano Deore, M6120, 4-Piston |
| Rotors (F/R) | Shimano SM-RT66, 203mm/180mm |
| Crankset | Shimano Deore M6120 24mm spindle, 30t Alloy Ring S-M: 165mm, XM-XL: 170mm |
| Bottom Bracket | Shimano SM BB52 |
| Rear Derailleur | Shimano Deore, M6100, Shadow Plus |
| Shifter | Shimano Deore, M6100 |
| Cassette | Shimano Deore, M6100, 10-51T |
| Chain | Shimano Deore, M6100 |
| Headset | Cane Creek 40 ZS44/ZS56 |
| Grips | Lizard Skin Charger |
| Handlebar | Ibis Hi Fi, 31.8mm, 800mm |
| Stem | Ibis 31.8mm S-M: 40mm, XM-XL: 50mm |
| Seatpost | KS Rage-i Dropper 34.9mm S: 125mm, M: 150mm, XM: 170mm, L-XL: 190mm |
| Saddle | WTB Silverado, Fusion, 142mm |
| Frame Weight | 7.6 lbs XM frame w/ Fox Float X |
| Wheel Size | Size XM-XL: 29" wheels Size SM-MD: MX wheels (MX or 29" option in all sizes via flip chip) |
| Tire Clearance | 2.5" |
| Front Travel | 160mm |
| Rear Travel | 150mm |
| Shock Specs | 230mm x 60mm (coil shock compatible) |
| Boost Axles | 148mm rear / 110mm front |
| Seatpost Diameter | 34.9mm |
| Rear Brake | 180mm Post mount / 220mm max rotor |
| Chainstay Length | 29": 435-440mm, MX: 432-437mm |
| Bottom Bracket | Threaded BB (73mm BSA) |
| Chainline | 55mm chainline |
| Derailleur Hanger | SRAM UDH |
| ISCG 05 Compatible | ISCG 05 Tab Mount available separately |
| Headset | ZS44 upper / ZS56 lower |
| Bottle Mounts | 22oz bottle on size small, 26oz on all other sizes |
| Frame Storage | Large Internal frame storage with easy access door |
| Frame Storage Bag | Sustainably sourced internal frame bags produced in partnership with Cotopaxi |
| Colors | Huckleberry Purple or Olive Swamp Monster |
| Sizes | Small (S), Medium (M), Extra medium (XM), Large (L) and Extra Large (XL) |
* Specs subject to change
